How to record or stream MacOS audio output with live feedback using iShowU Audio Capture

Dec 27, 2019 · 1 min read

There is no native way of recording a Mac’s output, so we are going to set up and install iShowU Audio Capture.

The result is going to be a virtual device, like a microphone, that “outputs your output”.

Note: if you don’t need to hear what you’re recording I recommend SoundFlower for its ease of use.

Installation and setup

1. Install iShowU Audio Capture

• If you’re on Catalina or later, you’ll need to accept the System Software from Shiny White Box Limited. It will be under Security and Privacy in your System Settings.

2. Once the installation finishes, you’ll have to restart your Mac. This allows the system to load the new kernel extension.

• If it worked, you should now have iShowU AudioCapture under the Sound-Output panel.

3. Go to Audio MIDI Setup

• Add a new Multi-Output Device.
• Tick iShowU Audio Capture and your audio output. In my case, it’s my headphones.
• Set the master device as your output device.

4. Under Sound se l ect the Multi-Output Device you created as your Output device. You will no longer be able to set the volume for this device, unfortunately.

5. Use iShowU Audio Capture as you would a microphone in any recording program on your Mac.

6. Have fun & profit!

My original source is this OBS forum post. If you prefer a video to follow along to, I highly recommend it.

Источник

Stream Audio To Anything

replaces the old iShowU Audio Capture driver

BigSur (macOS 11) New M1 Macs Intel Macs Watch Video examples for OBS, SLOBS, Discord & Zoom, with more being worked on.

Problem: Solved

Compatible with your app

Suitable for use with any app that can record audio on the mac, including Discord, OBS (+ variants), Zoom, MS Teams, or other streaming/live apps. If your app can use a microphone; it can work with SWB Audio App!

Full setup videos at the SWB Audio App channel

One Click

Enables audio capture (capturing all audio from the mac, and playing to your speakers or headset) with a single click.

Merge Mic & App Audio

Merge audio from both your computer & microphone at the same time, without the need for OBS/other apps.

The merged audio is usable as a single input device, making it super easy to share both high quality computer audio & mic audio on a call.
* great choice for Zoom, Discord or MS Teams.

Hotkeys Galore!

Assign hotkeys to all functions and any device.

• Toggle on/off preview
• Toggle on/off routing of microphone
• Control both preview and input devices directly from your Stream Deck ^

^ or other remote control that can drive hotkey combinations

Multiple Output Super-Assist!

Want to send audio to more than one output device? Have SWB Audio App create a suitable Multi-Output for you.

SWB Audio App includes an easy to use ‘Multi Output’ device creator, letting you create a special ‘virtual output device’ that can output audio to both speakers (or a headset) and the SWB Audio Capture driver at the same time.

This makes it easy to send audio to both the SWB Audio Capture driver; and other devices. You just choose the devices you want to join together and press ‘create’. Done. Watch the video multi-output video

Easy to Install & Use

Simple & Standalone

Self contained installer, with no extra apps required & no kexts!

Works with apps you already know

Developed with apps like OBS, Streamlabs OBS, Discord, Zoom (and more) in mind. Constantly evolving set of videos at our SWB Audio App channel.

Built-In Preview

Preview the audio to any device you like, speakers, headsets — whatever is connected to your mac.

Planned updates

Aggregate Support

Easy setup of «aggregate devices». Automatic setup of aggregate devices, so you don’t have to. Just choose the other devices you wish to «merge» with SWB Audio App, and it’ll do the rest.

Per App Audio (*almost done)

Set the levels for various apps independently. Want the app audio for some apps to be less? No problem; just lower the volume the slider for that app. Or mute it completely!

Note: these features are not 100% guaranteed to be in a future release, but are being actively developed with a view to being included, if they work well in practice.

Источник

[OS X]Capture audio with iShowU Audio Capture

If you prefer graphics, watch this helpful video by Chupacabra Tutorials:

So most of you know, to capture audio from a Mac you need an extension like Soundflower. But what most of you don’t know is that you can use another extension to capture audio. I present to you, iShowU Audio Capture!

CHECKLIST

• iShowU Audio Capture(duh): An extension used by iShowU Studio & iShowU Instant. It’s 101% free.
• Audio MIDI Setup: An audio utility. Comes with every version of Mac.

STEPS

1. Install iShowU Audio Capture(link in checklist) like you installed Soundflower.

2. (optional)Uninstall Soundflower.

3. Open Audio MIDI Setup. Click the «+» button at the bottom left of the window. Choose «Create Multi-Output Device».

4. Check the boxes for Built-in Output & iShowU Audio Capture in the «Use» column. Also check the box for Built-in Output in the «Drift Correction» column to prevent audio sync issues.

5. Open System Preferences, then go to Sound. In the Output section, select your newly created multi-output device.

6. Open OBS. Go to Settings, then Audio. Select iShowU Audio Capture as one of your Mic/Auxiliary Audio Device.

After this, you should be able to record & stream with audio. Enjoy!

Q: Why do you need to put the extension in Mic/Auxiliary Audio Device, not Desktop Audio Device?

A: In theory, Soundflower & iShowU Audio Capture are 2 different extensions. iShowU Audio Capture is a virtual mic while Soundflower is a virtual audio grabber. So any virtual mic goes into the Mic/Auxiliary Audio Device & any virtual audio grabber goes into Desktop Audio Device.

Q: Can you use this with Quicktime?

A: Absolutely! Just select iShowU Audio Capture in the Microphone section.

Q: Why does my video have no sound?

A: You opened the program you intended to record before switching to the Multi-Output Device. The device will only capture audio from any program opened after switching.

If you have any issues, click Discuss This Resource & tag my name 😀

Источник

OBS Studio [OS X]Capture audio with iShowU Audio Capture

amsyar ZeRo

Member

amsyar ZeRo submitted a new resource:

[OS X]Capture audio with iShowU Audio Capture — Another easy way to capture crisp audio from your Mac

If you prefer graphics, watch this helpful video by Chupacabra Tutorials:

Jovanka

New Member

amsyar ZeRo submitted a new resource:

[OS X]Capture audio with iShowU Audio Capture — Another easy way to capture crisp audio from your Mac

FleshyTemples

New Member

I’ve tried everything and simply can’t get OBS to read an audio signal from my Zoom Q2n camera (I get video just fine). I think I’ve done everything the video outlines, yet still. no audio from the camera (if it matters, I stream live music, so the singular sound source from my music mixer goes directly into the Zoom camera (and it reads the audio signal fine, thus it stands to reason if the Zoom is supplying the visual media into OBS just fine, it should the audio as well).

I’ve set up Multi-Output Device in Audio Devices setting on my Mac (I’ve tried making the Master Device both iShow and Built-in but neither works). In OBS Settings I have the mic/aux set to iShowU. Still nothing. I’m at a total loss and I’ve spent about two days trying to figure this out. Help, please!

Источник

OBS Studio [OS X]Capture audio with iShowU Audio Capture

TotnesChap

New Member

GeorgeFishers

New Member

MarkHicks

New Member

I’m using OBS to record programmes from a set top box. I’m using an iSolem HDMI splitter and a Zaycue Capture device. I’ve got perfect video but having set up the audio via iShareU exactly as shown, I’ve got nothing but silence. Any suggestions?

Filth Charl3s

New Member

Ok so I did literally everything click by click the exact same way that you did and the guy in the video did and when I go to OBS, the bars that show that it’s picking up sound still do not work. I know for a fact that it is capturing Desktop audio because I used Quicktime to record a video and it was able to capture the sounds from the game and the screen itself. The only issue is that OBS is still not detecting any desktop sounds.

Edit: I streamed on Twitch and my viewers said they couldn’t hear any audio either from my mic or from the game even while using iShareU Audio Capture having been set up as the video shows.

avatarhzh

New Member

I followed this guide https://obsproject.com/forum/resources/os-x-capture-audio-with-ishowu-audio-capture.505/ and OBS works correctly. I can record/stream to Youtube or Twitch. However now on my Mac I can’t adjust my volume anymore. So when I adjust my press my volume up/down keys, all I get is this:

I have a Macbook Air 2015 and my OS is Mojave 10.14.5

@amsyar ZeRo it’d be great . if you can help me with thiss issue

David_1970

New Member

amsyar ZeRo submitted a new resource:

[OS X]Capture audio with iShowU Audio Capture — Another easy way to capture crisp audio from your Mac

Hello,
I tried the method described here. The installation procedure is carried out until the end, successfully . but it is as if nothing were installed! I can’t find a program, I don’t find any trace of drivers in «audio» or even in the Midi program!

I can’t ear my desktop sounds in the recorded desktop video!!

MacBook Pro, macOS Mojave 10.14.6, 2,8 GHz Intel Core i7, 16GB 1600 MHz DDR3
OBS 23.2.1 (64bit)

How do I proceed? Thanks.

RodAbernethy

New Member

Hello, I’m a newbie and trying to use OBS to stream live video and audio. It’s great to be on the forum and have somewhere to ask questions about OBS.

I’m using a Macbook Pro with OBS and I’m using Digital Performer to bring in some external audio and microphones with a ZOOM H4N Pro as my USB interface.

Both Digital Performer and OBS are running on my Macbook Pro. I’d like to send my stereo output mix from Digital Performer into OBS, but OBS is not recognizing Digital Performer as an input for an audio source. Does anyone have any suggestions?

TheOriginalBudman

New Member

Hello, I’m a newbie and trying to use OBS to stream live video and audio. It’s great to be on the forum and have somewhere to ask questions about OBS.

I’m using a Macbook Pro with OBS and I’m using Digital Performer to bring in some external audio and microphones with a ZOOM H4N Pro as my USB interface.

Both Digital Performer and OBS are running on my Macbook Pro. I’d like to send my stereo output mix from Digital Performer into OBS, but OBS is not recognizing Digital Performer as an input for an audio source. Does anyone have any suggestions?

I’m a noob also. I puttered around with iShowU but had no more success than anyone else. I got in touch with the developer and tried a newer app called iShowU Instant which has problems of its own.’

I scrapped the whole thing and went to rogueamoeba’s Loopback. Much easier.
